| 規格書 |
| 局數 | 6 |
| 電壓值 | 12 V |
| 安培數 | 17 Ah @ 20hr-rate to 1.75V per cell @ 25°C (77°F) |
| 重量(kg) | Approx. 5.5 kg. (12.13 lbs.) |
| 最大放電電流5秒(A) | 230 A (5sec.) |
| 內阻(mΩ) | Approx. 16 mΩ |
| 溫度工作范圍 | Discharge：-15℃~50℃(5°F~122°F) Charge：-15℃~40℃(5°F~104°F) Storage：-15℃~40℃(5°F~104°F) |
| 一般使用溫度工作范圍 | 25°C ± 3°C (77°F ± 5°F) |
| 浮充使用充電條件 | 13.5 to 13.8 VDC/unit Average at 25°C (77°F) |
| 建議充電最大電流 | 5.1A |
| 均充使用充電條件 | 14.4 to 15.0 VDC/unit Average at 25°C (77°F) |
| 自放電 | It should be more than 75% of the capacity that before storage after stocked for 6 months at ambient temp. 25℃ |
| 端子 | B1/B3-L terminal to accept M5 nut & bolt |
| 電槽組材質 | ABS(UL94-HB) & Flammability resistance of(UL94-V0) can be available upon request. |
 |
| 尺寸 |
|
| 定電流放電特性表 單位: 安培(25°C,77°F) |
| 終止電壓/時間 | 5MIN | 10MIN | 15MIN | 30MIN | 60MIN | 90MIN | 2HR | 3HR | 5HR | 8HR | 10HR | 20HR |
| 1.60V | 80.20 | 50.90 | 38.50 | 23.40 | 13.80 | 10.10 | 8.03 | 5.72 | 3.63 | 2.37 | 1.93 | 1.00 |
| 1.67V | 71.20 | 47.50 | 36.50 | 22.90 | 13.70 | 10.00 | 7.99 | 5.69 | 3.61 | 2.35 | 1.90 | 0.95 |
| 1.70V | 67.40 | 45.80 | 35.60 | 22.70 | 13.60 | 10.00 | 7.97 | 5.67 | 3.61 | 2.35 | 1.89 | 0.94 |
| 1.75V | 61.00 | 43.10 | 34.10 | 22.30 | 13.40 | 9.86 | 7.92 | 5.64 | 3.59 | 2.32 | 1.86 | 0.91 |
| 1.80V | 54.50 | 40.20 | 32.70 | 21.80 | 13.30 | 9.79 | 7.87 | 5.61 | 3.58 | 2.30 | 1.83 | 0.88 |
| 1.85V | 48.00 | 37.30 | 31.00 | 21.20 | 13.10 | 9.68 | 7.80 | 5.56 | 3.56 | 2.27 | 1.80 | 0.85 |
| 定功率放電特性表 單位: 瓦特(25°C,77°F) |
| 終止電壓/時間 | 5MIN | 10MIN | 15MIN | 30MIN | 60MIN | 90MIN | 2HR | 3HR | 5HR | 8HR | 10HR | 20HR |
| 1.60V | 890.00 | 583.00 | 449.00 | 281.00 | 166.00 | 121.00 | 96.40 | 68.60 | 43.60 | 28.40 | 23.10 | 12.00 |
| 1.67V | 790.00 | 544.00 | 423.00 | 275.00 | 164.00 | 120.00 | 96.00 | 68.50 | 43.40 | 28.30 | 22.80 | 11.50 |
| 1.70V | 748.00 | 527.00 | 413.00 | 272.00 | 163.00 | 119.00 | 95.80 | 68.40 | 43.30 | 28.20 | 22.70 | 11.30 |
| 1.75V | 677.00 | 493.00 | 395.00 | 267.00 | 161.00 | 119.00 | 95.30 | 67.90 | 43.20 | 27.90 | 22.40 | 10.90 |
| 1.80V | 605.00 | 460.00 | 377.00 | 261.00 | 160.00 | 118.00 | 94.60 | 67.30 | 43.00 | 27.60 | 22.00 | 10.50 |
| 1.85V | 533.00 | 427.00 | 361.00 | 254.00 | 158.00 | 116.00 | 93.80 | 66.80 | 42.90 | 27.30 | 21.70 | 10.10 |
