英國WA CORBRONZE 302 G藥芯焊絲

備注：一口價為一公斤的價格

拍下時請注明規格 0.8/1.0/1.2/1.4/1.6

CORBRONZE 302 G

CLASSIFICATION

DIN 8555: MSG 31-GF-300-C
EN 14700: T Cu1

DESCRIPTION

? Special cored wire for GMAW
? The weld metal is a Cu - Mn - Ni - Al bronze
? Sound, pore free deposits on ferrous and non-ferrous base materials

APPLICATIONS

The building up of aluminium bronze, cladding components undergoing metal to metal wear under high pressure. Especially suited for marine environments. The addition of nickel improves corrosion resistance in heat and rough seawater. Excellent resistance to cavitation and stress corrosion cracking.

Examples
Ship propellers, shafts, guide grooves etc

TYPICAL ALL-WELD METAL ANALYSIS AlFeMnNiCu

11.50	2.00	1.00	4.80	Bal.

TYPICAL ALL-WELD METAL MECHANICAL PROPERTIES

Hardness – 3-layer deposit on mild steel: 320 HB

SHIELDING GAS ISO 14175: I1 (pure argon)
I3 (Ar + 30% He) OPERATING CONDITIONS Current typeGas flow rateRecovery

DC(+) continuous or pulsed	12 - 20 l/min.	90 %

Diameter [mm]Intensity [A] Voltage [V] Stick-out [mm] RangePulsedContinuousRangeOptimum

1.2	150 - 320	22 - 25	27 - 31	10 - 20	15
1.6	200 - 350	22 - 25	27 - 31	10 - 20	15

Stringer or weaved beads
Can be welded gun leading or gun trailing
The use of pulsed current is recommended for improved wetting and bead appearance
Higher currents and voltages can be used, but cause increased element burn-off (particularly Al) and dilution, leading to lower hardness levels.
Use of preheat and working temperatures up to 300°C will help forestall cracking.

WELDING POSITIONS

EN ISO 6947 : PA, PB
ASME IX: 1G, 1F, 2F

PACKAGING Diameter1.2 mm 1.6 mm

Spool type	EN ISO 544: BS300	EN ISO 544: BS300	EN ISO 544: B450
Weight	15 kg	15 kg	25 kg

Other packaging: please consult us
