AC and Pulse Metallized Polypropylene Film Capacitors MKP Radial Potted Type

APPLICATIONS
? Pulse operations
? SMPS and thyristor circuits
? Storage, filter, timing, sample and hold circuitsQUICK REFERENCE DATA
Capacitance range 4700 pF to 10 μF
Capacitance tolerances ± 20 % (M), ± 10 % (K), ± 5 % (J)
Climatic testing class according to IEC 60068 55/100/56
Operating temperature range -55 °C to +100 °C
Dielectric Polypropylene film
Electrodes Metallized
Construction Extended metallized film
(refer to general information following the link in note below table)
Coating Flame retardant plastic case, epoxy resin sealed
UL-class 94 V-0
Leads Tinned wire
Rated voltages (UR) 100 VDC, 160 VDC, 250 VDC, 400 VDC, 630 VDC
Insulation resistance
Measured at 100 VDC after one minute
For C ? 0.33 μF:
25 000 M? (UR 100 VDC)
Permissible AC voltages (RMS) up to 60 Hz 63 VAC, 100 VAC, 160 VAC, 220 VAC, 250 VAC
Test voltage (electrode/electrode) 1.6 x UR for 2 s
Time constant
Measured at 100 VDC after one minute
For C > 0.33 μF:
30 000 s minimum value
Temperature coefficient -250 x 10-6/°C (typical value)
Capacitance drift Up to +40 °C, < 0.5 % for a period of two years
Dielectric absorption 0.05 % (typical value) according to IEC 60068-2-21
Derating for DC and AC category voltage UC At +85 °C: UC = 1.0 UR
At +100 °C: UC = 0.7 UR
Self inductance ~ 6 nH measured with 2 mm long leads
Pull test on leads ??30 N in direction of leads according to IEC 60068-2-21

MKP1840310405D
MKP1840310405G
MKP1840310405F
MKP1840310405W
MKP1840522255V
MKP1840522255G
MKP1840547255
