Viking光頡CR-03FL7--1K現貨庫存量100000個，貼片厚膜電阻，光頡CR-03FL7-1K規格型號：阻值1KΩ，功率1/10W，封裝0603，溫漂100PPM。CR-03JL7--150K庫存170000個，CR-03JL7--1M現貨70000個，CR-06JL7--100R現貨60000pcs,CR-03JL7--330K庫存量60000pcs，CR-03JL7--330K庫存量50000pcs，CR-03JL7--2K2現貨45000個，AR03BTDY1603現貨35000個，AR02BTDY2003庫存10000個，CS05FTHR068庫存5000個，AR05FTDWR330現貨5000個，SWR06JTEO1000現貨5000個，SWR03JTEW6802現貨5K，CS13FTFUR390現貨5K，AR05FTDW1001，CS12FTGR330，CS12FTGR400，MC06KTB500332，AR05BTBX8982，AR05BTBX4991。
|
Item Type |
Power Rating at 70°C |
Operating Temp. Range | Max. Operating Voltage | Max. Overload Voltage | Resistance Range (E24、E96) |
TCR (PPM/°C) |
||
|---|---|---|---|---|---|---|---|---|
| ±0.1% | ±0.25% | ±0.5% | ||||||
| CR-02 (0402) | 1/16W | -55 ~ +155°C | 50V | 100V | - | 10Ω - 1MΩ | ±100 | |
| - | 1.02M - 10MΩ | ±200 | ||||||
| CR-03 (0603) | 1/10W | 75V | 150V | 10Ω - 1MΩ | ±100 | |||
| - | 1.02M - 10MΩ | ±200 | ||||||
| CR-05 (0805) | 1/8W | 150V | 300V | 10Ω - 1MΩ | ±100 | |||
| - | 1.02M - 10MΩ | ±200 | ||||||
| CR-06 (1206) | 1/4W | 200V | 400V | 10Ω - 1MΩ | ±100 | |||
| - | 1.02M - 10MΩ | ±200 | ||||||
| CR-10 (1210) | 1/3W | 200V | 400V | 10Ω - 1MΩ | ±100 | |||
| - | 1.02M - 10MΩ | ±200 | ||||||
| CR-0A (2010) | 3/4W | 200V | 400V | 10Ω - 1MΩ | ±100 | |||
| - | 1.02M - 10MΩ | ±200 | ||||||
| CR-12 (2512) | 1W | 250V | 500V | 10Ω - 1MΩ | ±100 | |||
| - | 1.02M - 10MΩ | ±200 | ||||||
General purpose thick film resistor , high power, low TCR is available.
CR Series0603 ±1% 100 1/10W Series1KΩ 5K/REEL
| Size | Tolerance | TCR (ppm /℃) | Power | Resistance (Ohm) | Package |
|---|---|---|---|---|---|
| 0603 | ±1% | 100 | 1/10W | 1K | 5K/REEL |
