| GOLD 510 | High Tech Ni-Cr-Mo |
|
| DESCRIPTION |
High recovery (170%) nickel base maintenance electrode. The highly corrosion resistant deposit combined with excellent mechanical properties makes this electrode a trouble shouter for many problems. Welding of dissimilar joints, difficult to weld steels (high carbon equivalent), cushion layer, special stainless steels. |
|
|
||
|
|
||
|
MECHANICAL PROPERTIES
|
Rm (Mpa)
|
Rp 0.2 (Mpa)
|
A5 (%)
|
|
|
Up To :
|
790
|
470
|
35
|
|
|
Hardness ~ 240 HB, 450HB after work hardening
|
||||
|
|
|
|
|
|
| PACKAGING DATA |
Size (mm)
|
2.5 x 350
|
3.2 x 350
|
4.0 x 350
|
|
| Kgs / Packets | 4.5 | 4.5 | 4.5 | ||
| Packets / carton | 4 | 4 | 4 | ||
| Kgs / carton | 18 | 18 | 18 | ||
| Welding instructions | Current (A) | 85 | 110 | 140 | |
