ROBOTOOL 34W-G

CLASSIFICATION

DIN 8555: MSG 6-GF-35-P

EN 14700: T ZFe8

DESCRIPTION

· Seamless high fill copper coated tubular wire for semi-automatic gas shielded hardfacing
· Unique welder appeal
· Deposition rate increased by up to 20% when compared to solid wire
· Strong and tough hot working steel type deposit for service temperatures up to 550°C
· Wire does not pick up moisture, the wire feeding properties are excellent
· Designed for welding in horizontal, horizontal-vertical and vertical-up positions

APPLICATIONS

Hardfacing parts undergoing metal-to-metal wear, compression and moderate impact loads at high temperatures.

Examples

Hot shear blades, hot and cold punching tools, forging dies, extrusion press pistons, forging and trimming tools etc.

TYPICAL ALL-WELD METAL ANALYSIS CMnSiCrMoWV

0.09

0.70

0.50

4.70

2.30

2.30

0.60

Structure: martensite

TYPICAL ALL-WELD METAL MECHANICAL PROPERTIES Hardness – 3-Layer deposit on mild steel: As welded 35 HRc  CONDITIONS OF USE Current typeShielding gas

DC (+)

Self shielded

OPERATING CONDITIONS DiameterIntensity[A]Voltage [V]Stick-out [mm][mm]Range Range
 Range

1.2	100 - 300		16 - 32		12 - 25
1.6	130 - 350		16 - 32		12 - 25

Recovery: > 98 %

WELDING POSITIONS

Robotool 34W-G is suitable as well for downhand as for positional welding by adapting transfer mode and welding parameters as for solid wires.

STANDARD DIAMETERS (mm)

1.2, 1.6
Other diameters: please consult us

PACKAGING Diameter  1.2 mm   1.6 mm

Spool type EN ISO 544	Spool : BS 300		Spool : BS 300
Weight	15 kg		15 kg

Other packaging: please consult us
