公稱尺寸（mm）

長（mm）

公差

圓度

直徑不一致

0.297～ 1.496

30

±0.3 μm

0.3 μm

0.3 μm

1.497～10.010

40

±0.3 μm

0.3 μm

0.3 μm

型號（套裝編號）

設定內容公稱尺寸（mm）

直徑以0.001mm遞增

數量

ET-03

0.297 0.298…0.309 0.310

14

ET-04

0.397 0.398…0.409 0.410

14

ET-05

0.497 0.498…0.509 0.510

14

ET-06

0.597 0.598…0.609 0.610

14

ET-07

0.697 0.698…0.709 0.710

14

ET-08

0.797 0.798…0.809 0.810

14

ET-09

0.897 0.898…0.909 0.910

14

ET-10

0.997 0.998…1.009 1.010

14

ET-11

1.097 1.098…1.109 1.110

14

ET-12

1.197 1.198…1.209 1.210

14

ET-13

1.297 1.298…1.309 1.310

14

ET-14

1.397 1.398…1.409 1.410

14

ET-15

1.497 1.498…1.509 1.510

14

ET-16

1.597 1.598…1.609 1.610

14

ET-17

1.697 1.698…1.709 1.710

14

ET-18

1.797 1.798…1.809 1.810

14

ET-19

1.897 1.898…1.909 1.910

14

ET-20

1.997 1.998…2.009 2.010

14

ET-21

2.097 2.098…2.109 2.110

14

ET-22

2.197 2.198…2.209 2.210

14

ET-23

2.297 2.298…2.309 2.310

14

ET-24

2.397 2.398…2.409 2.410

14

ET-25

2.497 2.498…2.509 2.510

14

ET-26

2.597 2.598…2.609 2.610

14

ET-27

2.697 2.698…2.709 2.710

14

ET-28

2.797 2.798…2.809 2.810

14

ET-29

2.897 2.898…2.909 2.910

14

ET-30

2.997 2.998…3.009 3.010

14

ET-31

3.097 3.098…3.109 3.110

14

ET-32

3.197 3.198…3.209 3.210

14

ET-33

3.297 3.298…3.309 3.310

14

ET-34

3.397 3.398…3.409 3.410

14

ET-35

3.497 3.498…3.509 3.510

14

ET-36

3.597 3.598…3.609 3.610

14

ET-37

3.697 3.698…3.709 3.710

14

ET-38

3.797 3.798…3.809 3.810

14

ET-39

3.897 3.898…3.909 3.910

14

ET-40

3.997 3.998…4.009 4.010

14

ET-41

4.097 4.098…4.109 4.110

14

ET-42

4.197 4.198…4.209 4.210

14

ET-43

4.297 4.298…4.309 4.310

14

ET-44

4.397 4.398…4.409 4.410

14

ET-45

4.497 4.498…4.509 4.510

14

ET-46

4.597 4.598…4.609 4.610

14

ET-47

4.697 4.698…4.709 4.710

14

ET-48

4.797 4.798…4.809 4.810

14

ET-49

4.897 4.898…4.909 4.910

14

ET-50

4.997 4.998…5.009 5.010

14

ET-51

5.097 5.098…5.109 5.110

14

ET-52

5.197 5.198…5.209 5.210

14

ET-53

5.297 5.298…5.309 5.310

14

ET-54

5.397 5.398…5.409 5.410

14

ET-55

5.497 5.498…5.509 5.510

14

ET-56

5.597 5.598…5.609 5.610

14

ET-57

5.697 5.698…5.709 5.710

14

ET-58

5.797 5.798…5.809 5.810

14

ET-59

5.897 5.898…5.909 5.910

14

ET-60

5.997 5.998…6.009 6.010

14

ET-61

6.097 6.098…6.109 6.110

14

ET-62

6.197 6.198…6.209 6.210

14

ET-63

6.297 6.298…6.309 6.310

14

ET-64

6.397 6.398…6.409 6.410

14

ET-65

6.497 6.498…6.509 6.510

14

ET-66

6.597 6.598…6.609 6.610

14

ET-67

6.697 6.698…6.709 6.710

14

ET-68

6.797 6.798…6.809 6.810

14

ET-69

6.897 6.898…6.909 6.910

14

ET-70

6.997 6.998…7.009 7.010

14

ET-71

7.097 7.098…7.109 7.110

14

ET-72

7.197 7.198…7.209 7.210

14

ET-73

7.297 7.298…7.309 7.310

14

ET-74

7.397 7.398…7.409 7.410

14

ET-75

7.497 7.498…7.509 7.510

14

ET-76

7.597 7.598…7.609 7.610

14

ET-77

7.697 7.698…7.709 7.710

14

ET-78

7.797 7.798…7.809 7.810

14

ET-79

7.897 7.898…7.909 7.910

14

ET-80

7.997 7.998…8.009 8.010

14

ET-81

8.097 8.098…8.109 8.110

14

ET-82

8.197 8.198…8.209 8.210

14

ET-83

8.297 8.298…8.309 8.310

14

ET-84

8.397 8.398…8.409 8.410

14

ET-85

8.497 8.498…8.509 8.510

14

ET-86

8.597 8.598…8.609 8.610

14

ET-87

8.697 8.698…8.709 8.710

14

ET-88

8.797 8.798…8.809 8.810

14

ET-89

8.897 8.898…8.909 8.910

14

ET-90

8.997 8.998…9.009 9.010

14

ET-91

9.097 9.098…9.109 9.110

14

ET-92

9.197 9.198…9.209 9.210

14

ET-93

9.297 9.298…9.309 9.310

14

ET-94

9.397 9.398…9.409 9.410

14

ET-95

9.497 9.498…9.509 9.510

14

ET-96

9.597 9.598…9.609 9.610

14

ET-97

9.697 9.698…9.709 9.710

14

ET-98

9.797 9.798…9.809 9.810

14

ET-99

9.897 9.898…9.909 9.910

14

ET-100

9.997 9.998…10.009 10.010

14
