租賃/銷售羅德與施瓦茨 | ROHDE/SCHWARZ R&S FSP3 3G頻譜儀

—分辨率帶寬1Hz - 10MHz —高選擇性的數字和FFT濾波器 —準峰值檢波器和EMI帶寬 —接口：GPIB、Centronics、RS232C —自動測量TOI、OBW、相位躁聲和ACP（R） —可在時域快速測量：最小掃描時間1μS —可作TDMA信號測量的門控掃描
全新的FSP產品系列將高端分析儀FSE和FSIQ的眾所周知的優點系統地集成到中級分析儀中。
FSP樹立了中端產品測量速度和精確度的標準，它采用了高度集成的前端和全數字信號處理的后端,并與R&S的先進ASIC相結合,是具有頂級指標和高可靠性的產品.
FSP3：9KHz - 3GHz
FSP7：9KHz - 7GHz
FSP13：9KHz - 13.6GHz
FSP30：9KHz - 30GHz
FSP40：9KHz - 40GHz
—同檔產品中屏幕最大
—分辨率帶寬1Hz - 10MHz
—高選擇性的數字和FFT濾波器
—準峰值檢波器和EMI帶寬
—接口：GPIB、Centronics、RS232C
—自動測量TOI、OBW、相位躁聲和ACP（R）
—可在時域快速測量：最小掃描時間1μS
—可作TDMA信號測量的門控掃描
Rohde & Schwarz FSP3 3 GHz Spectrum Analyzer
FSP is the ideal partner for both development and production, featuring the smallest level measurement uncertainty in its class, as well as excellent RF characteristics. The FSP is outstanding for its innovative measurement functions and incorporates proven technology with an all new hardware design to enable revolutionary performance, reliability and ease of service.
Frequency range 20Hz to 3GHz, 7 GHz, 13 GHz, 30 GHz and 40 GHz
Resolution bandwidth 1 Hz to 10 MHz
Displayed average noise level -155 dBm (1 Hz)
Phase noise -113 dB (1 Hz) at 10 kHz
Additional filters:
Channel filters from 100 Hz to 5 MHz and RRC filters
FFT filters from 1Hz to 30 kHz
EMI bandwidths and quasi-peak detector
Total measurement uncertainty 0.5 dB
Measurement routines for TOI, ACP(R), OBW, CCDF, APD, etc. as standard
Fast ACP in time domain
Up to 80 measurements per second (including trace transfer via GPIB)
Electronic attenuator
