主要零件材質
|
零件名稱 Part Name |
CF8系列 Line |
CF3系列 Line |
CF8M系列 Line |
CF3M系列 Line |
WCB系列 Line |
|
閥體/閥蓋 Body/Cap |
CF8 |
CF3 |
CF8M |
CF3M |
WCB |
|
閥板 Brake |
CF8 |
CF3 |
CF8M |
CF3M |
WCB |
|
閥桿 Stem |
F304 |
F304L |
F316 |
F316L |
1Cr13 |
|
填料 Stem Packing |
PTFE編織 |
PTFE編織 |
PTFE編織 |
PTFE編織 |
石墨 Graphite |
|
墊片 Gasket |
PTFE+304 |
PTFE+304L |
PTFE+316 |
PTFE+316L |
石墨 Graphite+304 |
|
壓蓋 Gland Flange |
CF8 |
CF3 |
CF8M |
CF3M |
WCB |
|
填料壓環 Stuffing Ring |
304 |
304L |
316 |
316L |
1CrMoA |
|
螺栓 Bolt |
A193-B8 |
A193-B8 |
A193-B8 |
A193-B8 |
35GrMoA |
|
螺母 Nut |
A194-8M |
A194-8M |
A194-8M |
A194-8M |
45 |
主要連接尺寸
|
型號Type |
規格Size(mm) |
尺寸（mm） |
||||||||
|
inch |
DN |
L |
D |
D1 |
D2 |
b |
Z-φd |
H |
D0 |
|
|
Z41W-150LB |
1/2″ |
15 |
108 |
89 |
60.5 |
35 |
12 |
4-φ15 |
155 |
120 |
|
3/4″ |
20 |
117 |
98 |
70 |
43 |
13 |
4-φ15 |
160 |
120 |
|
|
1″ |
25 |
127 |
108 |
79.5 |
51 |
14.5 |
4-φ15 |
200 |
140 |
|
|
1?″ |
32 |
140 |
117 |
89 |
64 |
16 |
4-φ15 |
245 |
160 |
|
|
1?″ |
40 |
165 |
127 |
98.5 |
73 |
17.5 |
4-φ15 |
285 |
180 |
|
|
2″ |
50 |
178 |
152 |
120.5 |
92 |
19.5 |
4-φ19 |
315 |
200 |
|
|
2?″ |
65 |
190 |
178 |
139.5 |
105 |
22.5 |
4-φ19 |
375 |
220 |
|
|
3″ |
80 |
203 |
190 |
152.5 |
127 |
24 |
4-φ19 |
400 |
240 |
|
|
4″ |
100 |
229 |
229 |
190.5 |
157 |
24 |
8-φ19 |
460 |
280 |
|
|
5″ |
125 |
254 |
254 |
216 |
186 |
24 |
8-φ22 |
540 |
300 |
|
|
6″ |
150 |
267 |
279 |
241.5 |
216 |
26 |
8-φ22 |
620 |
320 |
|
|
8″ |
200 |
292 |
343 |
298.5 |
270 |
29 |
8-φ22 |
800 |
400 |
|
|
10″ |
250 |
330 |
406 |
362 |
324 |
31 |
12-φ25 |
850 |
450 |
|
|
12″ |
300 |
356 |
483 |
432 |
381 |
32 |
12-φ25 |
1000 |
500 |
|
|
14″ |
350 |
381 |
533 |
476 |
413 |
35 |
12-φ29 |
1300 |
600 |
|
|
16″ |
400 |
406 |
597 |
540 |
470 |
37 |
16-φ29 |
1400 |
600 |
|
|
18″ |
450 |
432 |
635 |
578 |
533 |
40 |
16-φ32 |
1600 |
650 |
|
|
20″ |
500 |
457 |
698 |
635 |
584 |
43 |
20-φ32 |
1850 |
650 |
|
|
24″ |
600 |
508 |
813 |
749.5 |
692 |
48 |
20-φ35 |
2200 |
700 |
|
|
Z41W-300LB |
?″ |
15 |
140 |
95 |
66.5 |
35 |
15 |
4-φ15 |
155 |
120 |
|
?″ |
20 |
152 |
117 |
82.5 |
43 |
16 |
4-φ19 |
160 |
120 |
|
|
1″ |
25 |
165 |
124 |
89 |
51 |
18 |
4-φ19 |
200 |
140 |
|
|
1?″ |
32 |
178 |
133 |
98.5 |
64 |
19 |
4-φ19 |
250 |
160 |
|
|
1?″ |
40 |
190 |
156 |
114.5 |
73 |
21 |
4-φ22 |
290 |
180 |
|
|
2″ |
50 |
216 |
165 |
127 |
92 |
22 |
8-φ19 |
330 |
220 |
|
|
2?″ |
65 |
241 |
190 |
149 |
105 |
25 |
8-φ22 |
385 |
250 |
|
|
3″ |
80 |
283 |
210 |
168.5 |
127 |
29 |
8-φ22 |
410 |
280 |
|
|
4″ |
100 |
305 |
254 |
200 |
157 |
32 |
8-φ22 |
480 |
300 |
|
|
5″ |
125 |
381 |
279 |
235 |
186 |
35 |
8-φ22 |
630 |
350 |
|
|
6″ |
150 |
403 |
318 |
270 |
216 |
37 |
12-φ22 |
690 |
350 |
|
|
8″ |
200 |
419 |
381 |
330 |
270 |
41 |
12-φ25 |
830 |
450 |
|
|
10″ |
250 |
457 |
445 |
387.5 |
324 |
48 |
16-φ29 |
1003 |
500 |
|
|
12″ |
300 |
502 |
521 |
451 |
381 |
51 |
16-φ32 |
1137 |
600 |
|
|
14″ |
350 |
762 |
584 |
514.5 |
413 |
54 |
20-φ32 |
7489 |
750 |
|
|
16″ |
400 |
838 |
648 |
571.5 |
470 |
57 |
20-φ35 |
7581 |
800 |
|
|
18″ |
450 |
914 |
711 |
628.5 |
533 |
60 |
24-φ35 |
2017 |
850 |
|
|
20″ |
500 |
991 |
775 |
686 |
584 |
64 |
24-φ35 |
2228 |
900 |
|
|
24″ |
600 |
1143 |
914 |
813 |
692 |
70 |
24-φ41 |
2650 |
950 |
|
|
Z41W-600LB |
?″ |
15 |
165 |
95 |
66.5 |
35 |
15 |
4-φ15 |
155 |
120 |
|
?″ |
20 |
190 |
118 |
82.5 |
43 |
16 |
4-φ19 |
160 |
120 |
|
|
1″ |
25 |
216 |
124 |
89 |
51 |
18 |
4-φ19 |
200 |
140 |
|
|
1?″ |
32 |
229 |
133 |
98.5 |
64 |
21 |
4-φ19 |
250 |
160 |
|
|
1?″ |
40 |
241 |
156 |
114.5 |
73 |
23 |
4-φ22 |
290 |
180 |
|
|
2″ |
50 |
292 |
165 |
127 |
92 |
26 |
8-φ19 |
350 |
250 |
|
|
2?″ |
65 |
330 |
190 |
149 |
105 |
29 |
8-φ22 |
430 |
280 |
|
|
3″ |
80 |
356 |
210 |
168 |
127 |
32 |
8-φ22 |
470 |
300 |
|
|
4″ |
100 |
432 |
273 |
216 |
157 |
38 |
8-φ25 |
570 |
350 |
|
|
5″ |
125 |
508 |
330 |
266.5 |
186 |
45 |
8-φ29 |
700 |
400 |
|
|
6″ |
150 |
559 |
356 |
292 |
216 |
48 |
12-φ29 |
750 |
500 |
|
|
8″ |
200 |
660 |
419 |
349 |
270 |
56 |
12-φ32 |
830 |
600 |
|
|
10″ |
250 |
787 |
508 |
432 |
324 |
64 |
16-φ35 |
1210 |
650 |
|
|
12″ |
300 |
838 |
559 |
489 |
381 |
67 |
20-φ35 |
1350 |
700 |
|
|
14″ |
350 |
889 |
603 |
527 |
413 |
70 |
20-φ38 |
1600 |
750 |
|
|
16″ |
400 |
991 |
686 |
603 |
470 |
77 |
20-φ41 |
1800 |
800 |
|
|
18″ |
450 |
1092 |
743 |
654 |
533 |
83 |
20-φ44 |
2110 |
900 |
|
|
20″ |
500 |
1194 |
813 |
724 |
584 |
89 |
24-φ44 |
2350 |
950 |
|
|
24″ |
600 |
1397 |
940 |
838 |
692 |
102 |
24-φ52 |
2900 |
1000 |
|
